Description
(2026 Upgraded version)
The B-VRB is an all-vanadium redox flow battery test cell designed for vanadium battery energy storage research. The cell adopts a modular structure consisting of end plates, current collector plates, bipolar plates, and electrode frames. The bipolar plates are made of high-purity graphite with PEEK fixing rods to provide stable electrical connection and structural support.
Applications
- All-Vanadium Redox Flow Battery Testing
- Vanadium Ion Electrochemical Evaluation
- Battery Cycling Performance Studies
- Energy Storage Battery Research
Features
- Large Flow Channel Area: Provides a 50 cm² flow channel area and supports customization according to user requirements
- High-Purity Graphite Bipolar Plate: Ensures electrical conductivity during vanadium redox flow battery testing
- Modular Cell Configuration: Integrates end plates, current collectors, bipolar plates, and electrode frames into a complete test cell structure
- PEEK Fixing Rod Design: Provides stable fixation of the cell components
- Continuous Vanadium Ion Operation: Supports stable vanadium ion release during discharge experiments
Specifications
- Flow channel area: 50 cm² (customizable)
- Bipolar plate material: Graphite
- Fixing rod material: PEEK
