Flying CO₂ Laser Marking Machine

Categories: ,

Description

Technical parameters

Application: Most non-metals such as paper, plastic and rubber
Gross weight: 55Kg
Size: 142*51*62cm

Laser Source: CRD
Output power: 30W / 40W / 50W / 60W
Laser wavelength: 10.64 μm
Power consumption: 500W (110V / 240V Optional, 50HZ)
Minimum Line Width: 0.017mm
Marking speed: ≤7000mm / s (according to different materials)
Positioning accuracy: 0.01mm
Minimum Character: 0.2mm
Marking area: 110X110mm
Mark focal length: 130mm
Repetition rate: 30–60 KHZ
Minimum Spot diameter: 5.7–8mm
M: ≤1.6
Mark content: Chinese and English characters / numbers / graphics / date and time / serial number, etc.
Marking mode: Flying, static and pipeline
Structural material: high-quality aluminum alloy
Cooling method: air cooling
Communication: interface Ethernet, TCP/IP, RS232 editor and sensor input
Model with screen: 7-inch touch screen, supporting multiple languages
