Description
Application
Most non-metals such as paper, plastic and rubber
Gross weight: 120Kg
Size: 78*90*106cm
Technical parameters
Laser Source: JPT / Maiman / RFH
Output power: 3W / 5W / 10W / 15W
Laser wavelength: 355 nm
Power consumption: 500W (110V / 240V Optional, 50HZ)
Minimum Line Width: 0.017mm
Marking speed: ≤7000mm / s (according to different materials)
Positioning accuracy: 0.01mm
Marking area: 110X110mm (150, 220, 300, 450, 600mm optional)
Mark focal length: 130mm
Mark content: Chinese and English characters / numbers / graphics / date and time / serial number, etc. (More languages are available)
Marking mode: static
Structural material: high-quality aluminum alloy
Cooling method: water cooling
Communication: interface Ethernet, TCP/IP, RS232 editor and sensor input
Supported Windows: Windows XP, 7, 8, 10
