Description
Application
All metals and most non-metals such as paper, plastic and rubber
Gross weight: 55Kg
Size: 68*70*65cm
Technical parameters
Laser Source: Raycus / JPT / MAX
Output power: 20W / 30W / 50W / 70W / 100W / 350W
Laser wavelength: 1064 nm
Power consumption: 500W (110V / 240V Optional, 50HZ)
Minimum Line Width: 0.017mm
Marking speed: ≤7000mm / s (according to different materials)
Positioning accuracy: 0.01mm
Minimum Character: 0.2mm
Marking area: 110X110mm (150, 220, 300, 350, 450, 600mm optional)
Mark focal length: 130mm
Repetition rate: 30–60 KHZ
Minimum Spot diameter: 5.7–8mm
M: ≤1.6
Mark content: Chinese and English characters / numbers / graphics / date and time / serial number, etc.
Marking mode: static and pipeline
Structural material: high-quality aluminum alloy
Cooling method: air cooling
Communication: interface Ethernet, TCP/IP, RS232 editor and sensor input
Supported Windows: Windows XP, 7, 8, 10
