2H-Type Novel Electrochemical Cell ,H-FlowCell, C007-11

Category:

Description

Materials: PMMA, PTFE, PEEK

Electrode gap (anode–cathode distance): <14 mm

Typical Applications:

CO₂ Reduction reaction (CO₂RR)

Electrocatalysis studies

Hydrogen and oxygen evolution reactions (HER/OER)

Small-scale membrane electrode assembly (MEA)

Membrane material screening

Key Advantages

1. Low iR Drop Design
Maintains cell voltage <10 V at 2 A, with reference electrode positioned at near-zero
distance from the working electrode to minimize internal resistance.

2. Catholyte Flow Capability
Integrated inlet/outlet ports enable electrolyte circulation for
flow-based electrolysis; ports can be sealed when not in use.

3. Adjustable Salt Bridge Positioning
L-shaped side-mounted salt bridge allows fine-tuning
of the reference-to-working electrode distance.

4. Stabilized Salt Bridge Mount
Anti-shift fixture ensures stable placement of the salt
bridge while allowing precise positional adjustment.

5. Quick-Lock Cell Assembly
Quick-release clamp and fast-opening cover design enable easy membrane replacement

6. Leak-Proof Sealing
Fluororubber compression seal ensures high integrity against liquid leakage during extended operation.

7. Integrated Gas Channels
Cathode chamber includes submerged gas inlet and quick-connect outlet, promoting efficient gas–liquid contact and airtight performance.

8. Standardized Electrode Compatibility
Supports 6 mm rod-type working electrodes for plug-and-play integration with common setups

9. Real-Time Anode Venting.
Dedicated gas vent port on the anode side allows for dynamic gas release during reactions.

10.High-Purity Counter Electrode
99.99% pure platinum mesh counter electrode ensures stable and reproducible performance—superior to gold-plated alternatives.

11. Dual-Stage Sealing at Anode Interface
Tapered sealing structure ensures leak-proof operation while
allowing easy electrode installation
